The Nexperia PUMZ1,115 combines an NPN and PNP transistor pair into a compact SOT363 (TSSOP-6) surface-mount package, measuring just 2.1 mm × 1.25 mm × 0.95 mm, making it ideal for space-constrained designs. AEC-Q101 qualified, it's built for automotive-grade reliability, offering a rugged solution for modern electronic devices.
Product Exceptional Benefits and Features
- Ultra-compact dual arrangement reduces board space and simplifies design by integrating both NPN and PNP devices.
- Low VCEsat (~200 mV) enables efficient switching, minimizing voltage drop and power loss.
- High-frequency capability (100 MHz fT) supports rapid signal transitions in communication and switching circuits.
- Wide voltage and temperature tolerances ensure reliable performance across harsh automotive, industrial, and control-system environments.
- AEC-Q101 grade means enhanced durability for critical applications.
Materials and Dimensions
- Package: Plastic SOT363 (TSSOP‑6), surface-mount
- Size: ~2.1 mm × 1.25 mm × 0.95 mm
- Material: Silicon (Si) BJT transistors
Application Potential
Power management, signal amplification and switching, automotive electronics, compact battery-powered platforms, general-purpose logic functions, and mixed-signal interfacing.
