The Nexperia BCP54,115 is a highly reliable, 45 V, 1 A NPN medium-power transistor designed explicitly for global industrial and automotive applications. Housed in a compact SOT-223 surface-mount package, this device features exceptional thermal handling and is AEC-Q101 qualified, meeting stringent quality standards for high-reliability systems.
Crucial Features of the Product
- Voltage Rating: Collector‑Emitter Voltage (VCEO) up to 45 V, enabling robust performance in high-voltage applications.
- Current Rating: Continuous Collector Current up to 1 A, with peak pulses up to 2 A, ensuring resilience in surge conditions.
- Power Handling: Power Dissipation ranges from 650 mW (typical) to 2 W (mounting-dependent maximum), supporting a range of power-intensive tasks.
- Performance: A high transition frequency (~180 MHz) supports fast switching, while the DC gain (hFE) of at least 63 (at 150 mA) provides strong amplification.
- Saturation Voltage: Low VCE(sat) < 0.5 V at 0.5 A ensures efficient switching and energy savings.
Unmatched Benefits and Usage Information
- Versatile Use: Ideal for linear regulators, MOSFET gate drivers, low-side switching, audio frequency drivers, and battery-operated electronics.
- AEC-Q101 Certified: Meets automotive-grade reliability, making it suitable for harsh environments and extended temperature cycles.
- Compact & Efficient: SOT-223 package enables space-saving designs with excellent heat dissipation, supporting up to 2 W when properly mounted.
- Low Saturation & High Gain: Ensures clean switching and strong signal performance in power-efficient designs.
