ATTEND 119A‑99A00‑R02 Mini PCI Express Socket 52 Position SMT Right Angle 9.9 mm

The ATTEND 119A‑99A00‑R02 is a precision-engineered Mini PCI Express (Mini PCIe) edge connector, optimized for embedded computing, industrial modules, and expansion card applications. This 52-position female socket supports right-angle surface-mount installation and full PCIe compliance, delivering secure and reliable module interfacing.

Core Features and Benefits of the Mini PCI Express Edge Connector

• Connector Type: Mini PCIe female edge connector, right-angle, surface mount.
• Contact Count & Format: 52 positions, dual-row configuration with 0.031″ (0.80 mm) pin pitch.
• Height: 9.9 mm stack height design, ideal for compact systems.
• Materials: Phosphor bronze contacts with a gold flash finish; liquid crystal polymer (LCP) insulation for thermal and mechanical stability.
• Mounting & Termination: Right‑angle surface-mount connector, solder termination for PCB reliability.
• Operating Temp Range: –40 °C to +85 °C, suitable for industrial environments.
• RoHS Compliant: Supports global environmental standards.

Why Choose this Product?

This versatile Mini PCIe connector brings dependable performance in industrial, embedded, and telecom setups. Its gold-finish contacts resist corrosion and ensure lasting conductivity. The compact right-angle footprint simplifies PCB layout while maintaining compliance with Mini PCIe standards.
