The ATTEND Technology 123A‑58B01 is a premium M.2 (NGFF) B‑Key edge connector engineered for reliable high-speed data modules. This right-angle SMT connector, featuring 67 female contacts at a 0.50 mm pitch, ensures a compact, space-saving footprint. Designed with high-quality gold flash over nickel contacts, it provides excellent signal integrity and corrosion resistance, making it ideal for industrial, telecom, and embedded computing applications.
Features, Benefits, and Applications of the Product
- 67‑Contact, Dual‑Readout Design: Supports high-density signal routing for modern M.2 modules, common in SSDs and wireless cards.
- Right-Angle, SMT Mounting: Enables low-profile PCB integration, ideal for compact form factors and board-to-board stacking applications. Facilitates efficient board layout in densely designed areas.
- Robust Contact System: Copper alloy contacts, plated with gold flash over nickel, ensure low contact resistance and long-lasting performance.
- Compact Height (5.8 mm): Offers a balance between spacing and PCB space constraints, making it well-suited for slim modules.
- Current Rating (0.5 A): Supports adequate power delivery for most Mini PCIe and NGFF applications.
- Wide Operating Temperature –40 °C to +85 °C: Suits industrial-grade environments, rugged designs, and data communication systems.
- Packaging & Compliance: Available in tape and reel for efficient pick-and-place assembly and RoHS-compliant.
Why Buy It?
The 123A‑58B01 connector blends precision engineering with durability. Its compact 67-pin layout, reliable contact plating, and right-angle SMT design make it a go-to for manufacturers designing next-gen SSDs, wireless modules, and expansion cards. The combination of high-current capability and wide temperature tolerance ensures it excels in demanding global B2B environments.
