The ATTEND 112C TBAR R02 is a compact microSD card socket designed for reliable retention and repeatable mating in embedded systems, IIoT devices, and industrial electronics. The hinged lid mechanism secures the card against shock and vibration, while the right-angle, top-mount SMT layout supports automated assembly and dense PCB designs.
Unique Features of the Product
- Card type microSD, 8 positions
- Mounting SMT, right angle, top mount.
- Profile height 1.93 mm above board for compact enclosures.
- Contacts copper alloy with gold plating for low contact resistance and durability.
- Housing material thermoplastic.
- Rating AC test voltage 500 V.
- Operating temperature minus 40 to plus 85 °C.
Unparalleled Benefits to Users
- Secure retention. The hinged lid reduces accidental ejects compared with push-push styles, improving reliability in mobile or industrial gear.
- Assembly-friendly SMT pads and right-angle orientation simplify pick and place and streamline reflow builds.
- Signal integrity: Gold-plated contacts support consistent impedance and low wear across multiple insertion cycles.
- Space efficiency A 1.93 mm above-board profile helps meet tight mechanical envelopes in handheld and compact controllers.
Typical applications
Industrial cameras, data loggers, gateways, single-board computers, and HMI panels require removable flash storage with robust card retention. It supports high-speed bus modes of up to 104 MB/s and modern capacity types, including SDHC, SDXC, and SDUC, to meet bandwidth and storage requirements.
