The ATTEND 115U-A000 is a high-quality Nano SIM card connector designed for compact electronic devices that require reliable SIM card connectivity. Manufactured by ATTEND Technology, this surface-mount, right-angle connector features a 6-pin configuration with a push-pull insertion/removal mechanism, ensuring secure and efficient operation.
Unique Features of this Nano SIM Connector
- Mounting Type: Surface Mount, Right Angle
- Number of Positions: 6
- Insertion/Removal Method: Push In, Pull Out
- Contact Finish: Gold (10.0µin / 0.25µm)
- Height Above Board: 0.051" (1.30mm)
- Current Rating: 1A max.
- Voltage Rating: 30V
- Contact Resistance: 100mΩ
- Insulation Resistance: 1000MΩ
- Dielectric Withstanding Voltage: 500VAC
- Durability: 5,000 cycles
How It Benefits Users
- Compact Design: With a height of just 1.3mm, it is ideal for space-constrained applications.
- Reliable Connectivity: Gold-plated contacts ensure stable and durable electrical connections.
- Easy Integration: Surface-mount, right-angle orientation simplifies PCB layout and assembly.
- High Durability: Rated for 5,000 insertion cycles, suitable for long-term use in various devices.
Product Usage Information
- Mobile Devices
- IoT Systems
- Industrial Equipment
- Automotive Electronics
- Consumer Electronics
