The ATTEND 120C-835D00 is a high-performance, 24-position CFast card connector designed for seamless integration into compact electronic devices. Featuring a surface-mount, right-angle orientation, this connector ensures reliable data transfer and secure card retention, making it ideal for applications in digital imaging, industrial automation, and embedded systems.
How this Card Connector Benefits Users
- High-Speed Data Transfer: Supports SATA 3.0 data transfer speeds up to 600 MB/s, ensuring rapid and seamless transmission between the card and the host component.
- Compact Design: The 8.35mm height above board allows for space-saving integration into compact electronic devices.
- Durable Construction: With a durability rating of 10,000 insertion cycles, this connector offers long-term reliability.
- Secure Card Retention: The push-push insertion/removal method ensures secure card retention while allowing for easy removal.
Usage Recommendations
- Ideal for professional digital cinema cameras and high-end DSLRs requiring rapid and reliable storage.
- Suitable for embedded systems in industrial automation applications.
- Perfect for compact and efficient memory solutions in embedded systems.
- Applicable in various consumer electronics requiring secure and high-speed memory connections.
Key Specifications
- Number of Positions: 24
- Mounting Type: Surface Mount, Right Angle
- Contact Plating: Phosphor Bronze with 10µ" Gold
- Height Above Board: 8.35mm
- Voltage Rating: 100V AC/DC
- Current Rating: 1.5A
- Operating Temperature Range: -40°C to +85°C
- Durability: 10,000 insertion cycles
- Insertion Force: 28.8N max
- Extraction Force: 3.7~24.5N max
- Packaging Type: Tray
- Compliance: RoHS
