Winstar WH1602A‑TMI‑JT# Character LCD Display Module 16×2 STN Negative Blue Backlight White LED

wh1602a-tmi-jt Winstar WH1602A‑TMI‑JT# Character LCD Display Module 16×2 STN Negative Blue Backlight White LED
WH1602A-TMI-JT#
brand logo

HT Part No. HT204473

Mfr. Part No. WH1602A-TMI-JT#

Manufacturer: WINSTAR

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 4.89
Units Per Unit Price
1 - 4 £ 4.89
5 - 11 £ 4.53
12 + £ 4.17
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Outline Length 84.00mm
Outline Height 13.20mm
Rohs ROHS
Manufacturer WINSTAR
Character Size 2.95x5.55mm
Operating Temperature -20°C~+70°C
Packaging BOX
Backlight Type LED, White
LCD Mode STN Negative Blue
Display Format 16x2
View Area 66.00x16.00mm
Polarizer / View Direction Transmissive W.T 6:00
Character Font English, Japanese
Typical Supply Voltage 5V
Interface/Controller 6800
Outline Width 44.00mm
Keyword lcd, character lcd, lcd ekran, 16x2, winstar

More Information

The Winstar WH1602A‑TMI‑JT# is a compact, monochrome 16x2 character LCD module built for embedded systems, industrial controls, and instrumentation interfaces. With its STN negative blue transmissive display, COB design, and white LED backlight, this module ensures optimal legibility even in low-light conditions. Its durable construction and wide operating temperature make it suitable for diverse environmental conditions.

Crucial Features and Benefits of this LCD Display Module

  • Display Format: 16 characters × 2 lines.
  • LCD Type: STN negative blue, transmissive.
  • Backlight: White LED.
  • Character Format: 5×8 dot matrix.
  • Character Size: 2.95mm × 5.55mm.
  • Mounting Style: COB (Chip-on-Board).
  • Interface Type: 4/8-bit parallel (6800-style).
  • Optional Interfaces: Some variants support I²C/SPI via the RW1063 controller.

Product Use Cases

This module is ideal for:

  • Embedded microcontroller projects
  • Industrial automation panels
  • User-interface terminals
  • Diagnostic instruments

Why Buy It?

The Winstar WH1602A‑TMI‑JT# LCD delivers reliable performance, ease of integration, and global language support. Its widely compatible controller and proven design make it a go-to display solution for developers and engineers working in IoT, automation, and legacy system upgrades.
