The WH1602B3-TMI-JW# from Winstar is a 16x2 alphanumeric LCD module designed for precise, efficient, and reliable text output in embedded systems. Featuring a blue STN negative transmissive display with white characters, it offers excellent contrast and readability. Its compact 80mm x 36mm form factor and I²C interface (via the RW1063 controller) make it ideal for space-constrained applications requiring minimal wiring. The module supports both 5V and 3V logic levels, ensuring compatibility across a wide range of microcontrollers and development platforms. Additionally, the display supports custom character creation, allowing for tailored user interfaces.
Key Benefits of Using WH1602B3-TMI-JW# - Winstar Alphanumeric LCD Display:
- I²C Interface: Simplifies wiring and conserves I/O pins, ideal for microcontroller-based projects.
- High Contrast Display: A blue background with white characters ensures readability in diverse lighting conditions.
- Wide Operating Temperature: Functions reliably between -20°C to +70°C, suitable for various environments.
- Custom Character Support: Allows the creation of up to 8 custom characters for specialized applications.
- Compact Design: Slim profile (13.2mm thickness) fits well in space-limited applications.
- Low Power Consumption: Efficient operation with a typical supply current of around 1.2mA.
Typical Applications of WH1602B3-TMI-JW# - LCD Display:
- Industrial Control Panels: Displaying system statuses and parameters.
- Medical Devices: Providing clear readouts in diagnostic equipment.
- Home Automation Systems: User interfaces for smart home devices.
- Consumer Electronics: Information display in appliances and gadgets.
- Educational Projects: Ideal for learning and prototyping with microcontrollers.
- Automotive Displays: Instrument panels and dashboard indicators.
