The Winstar WH1602B-Y-YH-JT # delivers a durable, visually striking 16×2 STN positive, transflective character LCD with black text on a yellow-green background, engineered for robust global B2B and industrial deployments. It integrates an ST7066U controller and a standard 6800 4/8‑bit parallel interface, ensuring seamless integration for OEMs, embedded engineers, and professional designers.
Compact Design with Clear Visibility
Featuring a compact 80.0 × 36.0 × 13.2 mm COB form factor, the module provides a clear view area of 99 × 24 mm and an active area of approximately 94.8 × 20 mm, delivering crisp readability in space-constrained designs. Characters are defined with precision, measuring 2.95 × 5.55 mm, with a dot size of 0.55 × 0.65 mm and a dot pitch of 0.60 × 0.70 mm.
Reliable Performance in Challenging Conditions
Operating on a 3 V to 5 V logic supply, this display supports an operating range of –20°C to +70°C, backed by visible lightweight reliability in industrial-grade conditions. The transflective STN panel design enhances outdoor readability and allows low-power operation by leveraging both ambient and LED backlighting.
User-Focused and Globally Compatible
The module supports English, European, and Japanese fonts, making it ideal for multilingual global applications. Its transflective STN design strikes a balance between visibility and power efficiency, delivering a crisp display under varied lighting conditions.
Ideal for Industrial, IoT, and Embedded Applications
Whether in industrial instrumentation, smart meters, automotive dashboards, or outdoor control panels, the Winstar WH1602B‑YYH‑JT# offers a compelling mix of clarity, ruggedness, and integration simplicity. Its compact footprint and high-contrast display meet the demands of high-precision B2B and technical applications.
