The Winstar WH1604A‑TMI‑ET# is a robust 16×4 STN negative transmissive character LCD module, featuring a white LED backlight on a deep‑blue background for optimal contrast. Its built-in ST7066 controller and standard 6800 4/8-bit parallel interface ensure seamless integration with industrial, commercial, and embedded systems globally.
Compact Yet Readable Design
Measuring a compact 87 × 60 × 13.6 mm (max), the module offers a viewing area of 62 × 26 mm and an active display area of 56.2 × 20.8 mm, delivering clarity in tight panel spaces. Each character is defined with a 2.95 × 4.75 mm size, using 0.55 × 0.55 mm dots with a 0.60 × 0.60 mm pitch, ensuring crisp and readable text.
Reliable Performance Across Conditions
Designed for rugged applications, the WH1604A-TMI-ET # operates reliably in environments ranging from –20°C to +70°C and withstands storage conditions from –30°C to +80 °C. The white LED backlight enhances text visibility in low‑light settings and extends usability across various lighting conditions.
Global Interface and Font Compatibility
This module supports standard European and English character sets, making it suitable for B2B applications worldwide. The familiar COB construction and 6800 parallel interface simplify hardware integration for OEMs, embedded designers, and industrial engineers.
What Benefits Does It Offer to Users?
- High-contrast white-on-blue character display.
- Robust COB design with compact dimensions.
- Wide operating temperature range for industrial use.
- Standard interface and controller compatibility.
- Global language support for flexible deployment.
Usage Information
Ideal for use in instrumentation, control systems, diagnostics, or consumer electronics, the Winstar WH1604A‑TMI‑ET# delivers reliable performance, clarity, and ease of integration for technical buyers seeking durable, globally compatible display solutions.
