The Winstar WO12864A1‑TFH# delivers a high‑performance 128×64 monochrome graphic display featuring crisp black pixels on a white FSTN positive, transflective background, optimized for global technical and embedded applications. Its Chip-on‑Glass (COG) architecture provides a slim and rugged form factor, ideal for compact and reliable OEM designs.
Superior Readability with FSTN Technology
Despite its compact 60.1 × 44.5 × 5.01 mm profile, it maintains excellent readability. The display includes an active display area of 49.89 × 27.49 mm with a viewable area of 54.6 × 32.0 mm, and precise pixel clarity with 0.36 × 0.40 mm dot size and 0.39 × 0.43 mm pitch. The display supports 6 o’clock viewing orientation, ensuring visibility even at sharp angles.
Flexible Interfaces and Controller Support
Powered by the efficient ST7565P controller, the module supports versatile interfaces, including 6800/8080 parallel and SPI, enabling seamless integration in diverse hardware environments. It operates reliably from –20°C to +70°C, with storage tolerance ranging from –30°C to +80°C, making it crucial for applications in demanding industrial, transportation, and automotive sectors.
How It Benefits Users
- Ultra-compact COG design, slim, rugged, and space-efficient
- High-resolution 128×64 graphic display is excellent for detailed icons, menus, and data
- Flexible interface options, parallel and SPI support for easy integration
- Wide temperature tolerance is reliable across industrial and outdoor deployments
- High readability FSTN positive transflective LCD preserves clarity under varied light conditions
Reliable Performance Across Applications
Ideal for OEMs, designers, and embedded systems professionals requiring a compact yet capable graphical display with outstanding durability and clarity, the Winstar WO12864A1‑TFH# delivers performance without compromise.
