The Winstar WG12864B‑TMI‑V#N is a premium 128 × 64 monochrome graphic LCD module, featuring a white-on-blue STN transmissive display. Built on a 2.4-inch COB design and integrated with the NT7107/NT7108 controller, it delivers crisp visuals and fast, efficient rendering, using the widely supported 6800/8080 parallel interface for easy integration into industrial, OEM, and embedded systems worldwide.
Compact Design with Superior Visual Clarity
Measuring 75.0 × 52.7 × 8.9 mm, this module offers a viewing area of 58.8 × 31.4 mm and an active area of 55.01 × 27.49 mm. Dot resolution of 128 × 64, with 0.40 mm dots and 0.43 mm pitch, ensures sharp and precise graphics, even in compact embedded displays.
Reliable in Harsh Environments
Designed for durability, the WG12864B‑TMI‑V#N operates from –20 °C to +70 °C and withstands storage temperatures up to –30 °C to +80 °C. Powered by a standard 5V logic supply, it features a built-in negative voltage generator and supports duty cycling at 1/64 duty cycles for efficient performance.
Enhanced Readability with LED Backlight
Equipped with a white LED backlight, the display offers enhanced contrast and readability, even in low-light environments. The STN negative format further improves visibility by delivering crisp light-on-dark text and graphics.
Why Buy this Product?
This module combines compact, rugged construction with high-resolution graphic capability and standard interfacing, making it ideal for industrial control panels, instrumentation, smart meters, and embedded devices. Its DOC build, built-in voltage generator, and broad temperature tolerance make it a dependable choice for technical buyers seeking precision, durability, and global compatibility.
