Upgrade your embedded and industrial graphics with the Winstar WG12864E1-TMI-V#N, a high-resolution 128 × 64 dot-matrix graphic LCD featuring a classic white-on-blue STN negative transmissive display, engineered for clarity and durability. Powered by integrated NT7107/NT7108 controllers, this module supports a robust 6800 8‑bit parallel interface, simplifying integration for OEMs and developers worldwide.
Compact, Reliable Construction
The WG12864E1‑TMI‑V#N features a compact COB (Chip-on-Board) architecture, measuring 55.0 × 50.0 × 10.0 mm, with an active area of 40.92 × 26.92 mm within a view area of 43.5 × 29.0 mm. Dot resolution is precise, with pixel sizes of 0.28 × 0.35 mm and fine 0.32 × 0.39 mm dot pitch, all rendering smoothly under a 1/64 duty cycle.
Built-In Voltage and Wide Temperature Performance
Designed for practical deployment, this module incorporates a built-in negative voltage generator, eliminating the need for external contrast voltage circuits and streamlining system design. It operates reliably across a standard temperature range, from –20°C to +70°C (operating) and –30°C to +80°C (storage), ensuring robust performance in industrial and automotive environments.
Bright LED Backlight for Enhanced Readability
Equipped with a white LED backlight, the WG12864E1‑TMI‑V#N ensures vivid display contrast even in low-light scenarios, enhancing readability in control panels, portable instrumentation, and automotive dashboards.
Global B2B-Ready Graphic Display
With its compact footprint, high‑resolution graphic capability, built‑in voltage regulation, and robust interface compatibility, the Winstar WG12864E1‑TMI‑V#N is a reliable choice for global B2B and technical buyers seeking a professional-grade graphic LCD for embedded systems, industrial equipment, automotive dashboards, and innovative instrumentation.
