The Winstar WG12864B-Y-YH-V #N combines precision and readability in a compact 128×64 STN positive transflective graphic LCD, complete with a yellow-green LED backlight, perfect for harsh environments and industrial-grade displays. Controlled by NT7107/NT7108 drivers and interfacing via an 8‑bit 6800 parallel bus, this module promises seamless integration for OEMs, embedded systems designers, and B2B technical buyers.
Compact Graphic Display with Sharp Resolutions
With a sleek COB structure measuring just 75 × 52.7 × 8.9 mm, the module offers a generous viewing area of 58.8 × 31.4 mm and an active area of 55.01 × 27.49 mm. The 0.40 × 0.40 mm dot size and 0.43 mm dot pitch guarantee fine detail and crisp readability in graphical interfaces.
Reliable Performance Across Wide Conditions
Designed to thrive in temperature extremes, the WG12864B-YYH-V #N operates from –20°C to +70°C and can be safely stored between –30°C and +80 °C. Powered by a standard 5 V logic supply and featuring built-in negative voltage, it sustains consistent performance across varying power environments.
High Visibility, Low Integration Effort
The transflective STN panel ensures excellent contrast under both backlit and ambient lighting, ideal for outdoor displays and low-light conditions. The yellow-green LED backlight further enhances legibility while keeping power consumption efficient. The familiar 6800‑style interface accelerates firmware development and system compatibility.
Ideal For Global Embedded and Industrial Displays
From diagnostic instruments to machine control panels, this module offers unbeatable performance in a space-saving form. Its COB build, robust graphic resolution, and industrial-grade reliability make it a versatile choice for global applications that demand clarity and endurance.
