NXP HEF4007UBT,653 Dual Complementary Pair Inverter IC SOIC14

The Nexperia HEF4007UBT,653 is a versatile dual complementary pair plus inverter logic IC, designed for high-reliability mixed-voltage circuits. It is housed in a compact SOIC‑14 (SOT108‑1) package, delivering efficient performance across demanding environments. This wide supply range enables seamless integration into both legacy 5 V designs and modern low-voltage systems.

Core Features and Benefits of the Product

• Low‑Power CMOS Design: Ultra-small power draw with quiescent current ≈ 4 µA and supply current ~30 µA, aiding energy-efficient designs.
• Robust ESD Resilience: Exceeds HBM > 2000 V and CDM > 1000 V, ensuring durability in ESD-prone environments.
• JEDEC Compliant (JESD 13‑B): Guarantees standardized, predictable behavior.
• Ambient Temperature Range: −40 °C to +85 °C, suitable for industrial and automotive-grade applications.
• Propagation Delay: Efficient switching times, 80 ns at 5 V, 40 ns at 10 V, 30 ns at 15 V.
• Compact SOIC‑14 Package: Small footprint (8.75 mm × 4 mm × 1.45 mm) perfect for space-constrained PCB layouts.

Applicable Areas

Engineered for signal conversion, buffering, and logic inversion in mixed-voltage systems. Typically used in industrial machinery, automotive electronics, telecom equipment, and multi-supply embedded systems requiring energy-efficient, high-noise immunity components with ESD protection.
