ATTEND 126A‑92A10 DDR5 SODIMM Socket Reverse 9.2 mm SMT Gold Flash 262 Pin

The ATTEND 126A-92A10 is a high-performance DDR5 SODIMM socket designed for modern computing applications requiring high-speed memory interfaces. With a 262-pin configuration and a 9.2mm height, this socket offers a compact solution for integrating DDR5 memory modules into space-constrained devices. Its reverse orientation ensures compatibility with various motherboard layouts, making it versatile for different design requirements.

Unmatched Advantages of Choosing this DDR5 SODIMM Socket

• High-Speed Performance: Supports DDR5 memory modules for enhanced data transfer rates.
• Compact Design: 9.2mm height and 262-pin configuration save valuable PCB space.
• Reliable Connectivity: Copper alloy contacts with selective gold plating ensure durable and stable connections.
• Broad Compatibility: Reverse orientation suits various motherboard layouts.
• Durable Construction: Rated for 50 cycles of insertion and extraction, ensuring long-term reliability and durability.

Why Choose the ATTEND 126A-92A10

This versatile DDR5 SODIMM socket ensures reliable and high-speed memory connectivity in your electronic designs. Its high-density 262-pin configuration supports the latest DDR5 memory modules, providing increased bandwidth and improved performance over previous generations. The reverse orientation and surface-mount design facilitate easy integration into compact and high-performance devices.

Use Cases

• Embedded Systems
• Industrial PCs
• Networking Equipment
• Consumer Electronics
• Servers and Workstations

Product Technical Specifications

• Pin Count: 262
• Height: 9.2 mm
• Orientation: Horizontal Reverse
• Mounting Type: Surface Mount (SMT) Right-Angle
• Contact Finish: Copper Alloy with Selective Gold Plating
• Material: High-Temperature Thermoplastic (LCP)
• Current Rating: 0.6 A per Pin
• Voltage Rating: 25 V AC/DC
• Operating Temperature Range: -40°C to +85°C
• Durability: 50 Cycles
• Insertion Force: 59.8 N Max
• Extraction Force: 44.6 N Max
• Contact Resistance: 60 mΩ Max
• Insulation Resistance: 100 MΩ Min
• Dielectric Withstanding Voltage: 500 VAC
