ATTEND 124A‑52A13 DDR4 SODIMM Socket Reverse 5.2 mm SMT Gold Flash 260 Pin

The ATTEND 124A-52A13 is a high-performance DDR4 SODIMM socket designed for compact computing applications. With 260 positions and a 5.2mm height, it offers a space-efficient solution for modern laptops, embedded systems, and industrial PCs. Its reverse keying ensures correct module orientation, enhancing system reliability.

Technical Specifications of this DDR4 SODIMM Socket

• Mounting Type: Surface Mount, Right Angle
• Mounting Feature: Reverse Key
• Contact Finish: Gold
• Contact Finish Thickness: Flash
• Height: 5.2mm
• RoHS Compliant: Yes
• Operating Temperature Range: -40°C to +85°C
• Durability: 50 cycles
• Insertion Force: 59.8N Max
• Extraction Force: 44.6N Max
• Current Rating: 0.6A per pin
• Voltage Rating: 25V AC/DC
• Contact Resistance: 60mΩ
• Insulation Resistance: 100MΩ
• Dielectric Withstanding Voltage: 500VAC

Why Buy It?

This socket supports data transfer rates up to 3200 MT/s, facilitating faster data processing and improved system performance. Its surface-mount design allows for efficient PCB integration, saving valuable space in compact devices. The reverse keying feature prevents incorrect module insertion, reducing the risk of damage and ensuring system stability.

• Unmatched Advantages to Customers
• Supports DDR4 memory modules for enhanced data transfer rates.
• 5.2mm height and 260-pin configuration optimize space utilization.
• Reverse keying ensures correct module orientation and prevents improper insertion.
• Gold-plated contacts provide outstanding conductivity and resistance to corrosion.
• Surface-mount right-angle design simplifies PCB assembly.

Product Usage Recommendations

• Laptops and Notebooks: Ideal for upgrading memory in portable computing devices.
• Embedded Systems: Suitable for industrial and automotive embedded applications requiring compact memory solutions.
• Networking Equipment: Enhances performance in routers, switches, and other network devices.
• Industrial PCs: Provide reliable memory connections in rugged industrial computing environments.
• Consumer Electronics: Applicable in gaming consoles, set-top boxes, and other consumer devices.
