The Nexperia HEF4016BT,653 is a high-performance quad single-pole single-throw analog switch, offering four independent bidirectional transmission gates with enable control. Designed for demanding mixed-signal environments, it supports a wide 3 V to 15.5 V supply range, low-power CMOS operation, and resilient performance across a temperature range of -40°C to +85 °C. Featuring a maximum on-time of 30 ns and an off-time of 100 ns, it enables rapid gating and signal control in high-speed applications.
Standout Features and Benefits of the Product
- Wide Supply Voltage (3 V–15 V): Offers flexibility in integrating logic and analog circuits.
- Low‑Power CMOS Design: Consumption under 4 µA, ideal for energy-conscious systems.
- High‑Impedance OFF State: Ensures signal integrity with low leakage (~200 nA).
- Consistent Performance: On‑state resistance (RON) around 350 Ω, with channel‑to‑channel mismatch within 10 Ω.
- Robust ESD Protection: HBM > 2000 V, CDM > 1000 V, enhancing reliability in noisy environments.
- Fast Switching Capability: Enables agile signal gating for dynamic applications.
- Compact Package: SOIC‑14 (SOT108‑1) footprint (approx. 8.65 mm × 3.9 mm; height ~1.75 mm).
Broad Range Application
Ideal for analog multiplexing, signal gating, demodulation/modulation, chopper circuits, and control interfaces in industrial, automotive, instrumentation, and communication systems.
