NXP HEF4016BT,652 Compact Quad SPST CMOS Analog Switch with Clamp Diodes

The Nexperia HEF4016BT,652 offers a compact, quad single-pole single-throw (SPST) CMOS analog switch, ideal for high-performance electronic systems requiring refined signal gating and multiplexing. Moreover, it excels in analog/digital multiplexing, signal gating, and routing, delivering fast, reliable switching with excellent analog fidelity. Its robust voltage range, ESD resistance, and compact footprint make it perfect for industrial control, test instrumentation, audio/video signal routing, and embedded systems.

Product Technical Specifications

• Supply Voltage: Operates across a broad 3–15 V (or up to 15.5 V) range, ensuring compatibility with diverse power domains.
• On‑Resistance: Typical maximum 350 Ω, with excellent inter-channel matching ΔRON ≈ 10 Ω, enabling reliable analog path integrity.
• Switching Performance: Fast response with turn‑on delay ≤ 30 ns and off‑time ≤ 100 ns, significant for dynamic switching applications.
• Low Power & ESD Protection: The CMOS design delivers µA-level supply current, while robust ESD resilience (HBM > 2000 V, CDM > 1000 V) ensures durability in harsh environments.
• Signal Integrity: Outstanding crosstalk suppression (–50 dB at 1 MHz) and high noise immunity support clean analog/digital signal handling
• Operating Range: Rated for –40 °C to +85 °C, offering dependable performance across diverse environments.
