NXP BAS16W,115 High‑Speed Switching Diode (100 V, 175 mA) in SOT‑323

The NXP BAS16W,115 is a compact, high-speed switching diode housed in a miniature SOT-323 (SC-70) surface-mount package, offering a robust reverse voltage rating of up to 100 V and a continuous forward current of 175 mA. Ideal for compact, fast-switching, general-purpose applications, it combines lightning-fast response, minimal capacitance, and negligible leakage, making it exceptionally efficient and reliable in modern electronic designs.

What Benefits Do You Get?

The BAS16W’s standout advantage is its ultra-fast switching capability (reverse recovery time ≤ 4 ns), enabling rapid signal transitions with exceptional efficiency. Its very low capacitance and leakage current help maintain signal integrity and power efficiency, while its compact SOT 323 surface mount format saves board space and supports automated assembly. With a high voltage tolerance of up to 100 V, it delivers durability and consistent performance across diverse applications—from high-speed logic circuits to switching power supplies and general switching tasks.

Product Functional Highlights:

• High switching speed (reverse recovery time trr ≤ 4 ns)
• Low capacitance aiding signal fidelity and efficiency
• Minimal leakage current for reduced power loss
• High reverse voltage tolerance (Vr and VRRM ≤ 100 V)
• Compact SOT-323 (SC-70) surface-mount package for space-constrained designs
• Continuous forward current rating up to 175 mA
• Peak non-repetitive forward surge handling up to 4 A.
