The Nexperia BAS321,135 is a compact, high-performance general-purpose switching diode engineered for global B2B and technical applications. Housed in a space-saving SOD-323 plastic package (~1.7 × 1.25 × 0.95 mm), this diode delivers exceptional performance where PCB real estate and reliability are a concern.
Special Features of the Product
- Reverse Voltage (VR): Supports up to 200 V continuous, with a repetitive peak rating of 250 V, ensuring robust over-voltage protection.
- Forward Current: Capable of handling 250 mA continuous and 625 mA peak, ideal for fast switching and pulse applications.
- Switching Speed: Blazingly fast with reverse recovery time ≤ 50 ns, minimizing switching losses and EMI.
- Forward Voltage (VF): Low voltage drop of ~1.0 V at 100 mA, rising to ≤ 1.25 V at 200 mA, optimizing efficiency.
- Leakage & Capacitance: Ultra-low reverse leakage current (100 nA @ 200 V) and minimal two pF junction capacitance, enhancing signal integrity and reducing losses.
Unparalleled Benefits to Users
- Minimal board footprint, ideal for dense PCB layouts in telecom, industrial, and consumer electronics applications.
- High voltage resilience and fast switching make it ideal for switching regulators, voltage clamping, and general signal switching roles.
- Efficient performance with low VF and leakage, prolonging battery life in power-sensitive applications.
- Robust thermal tolerance, with junction temperature up to +150 °C for demanding environments.
Versatility in Applications
This diode is well-suited for surface-mounted circuits, including Switched-Mode Power Supplies (SMPS), reverse polarity protection, voltage clamping, and signal switching, especially where compactness and reliability intersect.
