Nexperia BAV199,215 Low‑Leakage Dual Switching Diode (SOT‑23)

The Nexperia BAV199,215 is a dual-series epitaxial switching diode, optimized for performance in low‑leakage, high‑reliability SMD applications. Packaged in a compact SOT-23-3 plastic case, this diode pair is ideal for technical and industrial designs that require precision and efficiency.

Product Technical Specifications

• Reverse Voltage (VR): Up to 75 V continuous, 85 V repetitive peak robust protection against reverse transients.
• Forward Current (IF): 160 mA DC per diode; surge handling up to 4 A (1 µs pulse).
• Forward Voltage (VF): Max 1.25 V at 150 mA, ensuring low conduction loss.
• Leakage Current (IR): Ultra‑low ~3 pA typ. (up to 80 nA at 150 °C) for high‑precision and low‑power applications.
• Reverse Recovery Time (trr): Fast switching at ~0.8 µs typical, <3 µs max.
• Temperature Range: Operates reliably from −65 °C to +150 °C.

Notable Advantages to Users

• Exceptional reliability and low noise, due to ultra‑low leakage current, ideal for precision signal processing.
• Fast switching capability supports efficient high‑speed digital and analog circuits.
• The compact SOT-23-3 format suits dense PCB layouts and automated surface mounting.
• High surge and voltage tolerance protects sensitive components from transient spikes.
• Wide temperature tolerance validated for harsh industrial and aerospace environments.

Material and Dimensions

• Package material: Molded plastic (SOT‑23‑3), moisture sensitivity level 1, RoHS‑compliant; “green” variant available.
• Typical Dimensions: ~2.9 mm × 1.3 mm × 1 mm (L × W × H).

Usage Recommendations

Ideal for industrial control systems, precision instrumentation, power management circuits, and mixed-signal electronics, where low leakage, fast switching, and space-efficient packaging are essential.
