The Panjit US1DR100001 is a high-performance surface-mount rectifier engineered for ultra-fast switching and efficient power conversion. Packaged in the compact DO-214AC (SMA) format, this diode delivers 1A average forward current and can handle up to 200V reverse voltage, making it a dependable choice for various applications. Moreover, with its glass-passivated junction and Schottky barrier construction, it ensures minimal reverse leakage and low forward voltage drop, thereby reducing heat generation and boosting energy efficiency in compact circuits.
Product Technical Specifications
- Mounting: Surface-Mount (SMD).
- Package: DO-214AC (SMA).
- Max Reverse Voltage (VR): 200V.
- Average Forward Current (IF): 1A.
- Peak Surge Current (IFSM): 30A.
- Recovery Time: ~500ns.
- Operating Temperature: -55°C to +150°C.
Wide Application Range
Ideal for use in:
- AC-DC converters
- Switching power supplies
- Polarity protection circuits
- Freewheeling diodes in motor drives
- High-efficiency compact rectification designs
Why Buy It?
If you're building a space-saving high-efficiency circuit, the US1DR100001 is a top-tier diode offering fast recovery, reduced power loss, and excellent thermal performance. Its SMA footprint is perfect for surface-mount designs in densely populated boards, while its electrical robustness suits both low- and high-voltage projects.
