NXP PMEG4005CT,215 Dual Schottky Rectifier SOT‑23

The Nexperia PMEG4005CT215 is a highly efficient, dual Schottky barrier rectifier packaged in a compact SOT-23 (TO-236AB) form factor. Engineered for reliability and stress protection, it features an integrated guard ring and a common‑cathode configuration, making it ideal for compact power applications. Overall, it stands out as a rugged, efficient, and versatile dual-channel Schottky rectangle, engineered for modern power system demands. It combines low forward voltage, fast switching, high surge resilience, and thermal endurance, all in a miniaturized SMD package.

Key Specifications of the Product

• Voltage Rating: 40 V (repetitive peak reverse voltage).
• Current Rating: 500 mA average per diode; 10 A forward surge capacity.
• Forward Voltage (VF): ≤ 470 mV @ 500 mA.
• Reverse Recovery Time (trr): ~13 ns, ideal for high-frequency switching.
• Package & Size: SOT‑23‑3 (approx. 2.9 × 1.3 × 1 mm).
• Max Operating Temperature: +150 °C
• Technology & Configuration: Planar Schottky. (MEGA), common‑cathode pair, guard‑ring enhanced for rugged use.

Unmatched Benefits and Use Cases

• Ultra-low forward voltage drop reduces conduction losses, vital for power management, SMPS, DC-DC converters, and LED backlighting systems.
• Fast Switching Speed (t_rr ~13 ns) enhances efficiency in switching workloads.
• High Surge Capability (10 A) ensures robustness in transient scenarios.
• High Temperature Endurance (up to 150 °C) suits automotive and industrial environments.
• Compact SOT-23 packaging optimizes PCB real estate, crucial for space-limited designs.
