STM TYN825RG, THYRISTOR DIS.SINGLE 16A 800V TO220AB THT

tyn825rg STM TYN825RG, THYRISTOR DIS.SINGLE 16A 800V TO220AB THT
TYN825RG
brand logo

HT Part No. HT256324

Mfr. Part No. TYN825RG

Manufacturer: STM

Technical Documents: Datasheet(datasheets)

1474 - In Stock pcs
Price:
£ 1.39
Units Per Unit Price
1 - 49 £ 1.39
50 + £ 1.26
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Forward Drop (VT) 770mV
Applications N/A
Voltage (VRRM) 800V
Junction Temperature (Tj) N/A
Manufacturer STM
Current Hold (IH) 50mA
Power Dissipation N/A
Current On State (ITav) 16A
Trr N/A
Configuration Single
Rohs ROHS
Packaging TUBE
Series Thyristor Standard SCRs
Mounting Type THT
Package / Case TO220AB
RMS On State (ITrms) 25A
Current Temperature (IC) 100°C
Gate Trigger (Vgt) 1.3V
Tq N/A
Operating Temperature -40°C~+125°C

More Information

The STM TYN825RG is a single thyristor device designed for high-power applications. It features a maximum current capacity of 16A and a peak voltage rating of 800V, housed in a TO-220AB package suitable for through-hole technology (THT) mounting.

Unique Advantages of Using the STM TYN825RG, Single Thyristor

  • Through-hole technology (THT) mounting
  • High current and voltage ratings for robust performance in demanding applications
  • Reliable and efficient switching capabilities
  • Easy to mount and integrate into existing circuits with THT
  • Durable TO-220AB package ensures long-term reliability

Application Versatility of the STM TYN825RG, Single Thyristor

  • Power control and rectification in industrial machinery
  • Voltage regulation and motor control in consumer electronics
  • Lighting dimmer circuits
  • Overvoltage protection in power supplies
  • High-power AC switching and control systems
