HT Part No. HT17677
Mfr. Part No. NYC0102BLT1G
Manufacturer: Littelfuse
Technical Documents: NYC0102BLT1G, Sensitive Gate Silicon Controlled Rectifier (SCR)-59ee0e06(datasheets)
| Product Attributes | |
|---|---|
| Rated Average On-State Current | 0.25A |
| Thyristor Type | SCR |
| Package Type | SOT-23 |
| Repetitive Peak Reverse Voltage | 200V |
| Surge Current Rating | 7A |
| Mounting Type | Surface Mount |
| Maximum Gate Trigger Current | 200µA |
| Maximum Gate Trigger Voltage | 0.8V |
| Maximum Holding Current | 6mA |
| Pin Count | 3 |
| Dimensions | 2.9 x 1.3 x 0.94mm |
| Repetitive Peak Forward Blocking Voltage | 200V |
| Minimum Operating Temperature | -40 °C |
| Repetitive Peak Off-State Current | 100µA |
| Maximum Operating Temperature | +125 °C |
| Peak On-State Voltage | 1.7V |
