HT Part No. HT26674
Mfr. Part No. BTA25-600B
Manufacturer: STMicroelectronics
Technical Documents: Datasheet-96d11a5d(datasheets)
| Product Attributes | |
|---|---|
| Rated Average On-State Current | 25A |
| Mounting Type | Panel Mount |
| Package Type | RD-91 |
| Maximum Gate Trigger Current | 100mA |
| Repetitive Peak Reverse Voltage | 800V |
| Surge Current Rating | 260A |
| Pin Count | 3 |
| Maximum Gate Trigger Voltage | 1.3V |
| Repetitive Peak Forward Blocking Voltage | 600V |
| Maximum Holding Current | 80mA |
| Dimensions | 40 x 27 x 14mm |
| Length | 40mm |
| Width | 27mm |
| Height | 14mm |
| Minimum Operating Temperature | -40 °C |
| Peak On-State Voltage | 1.55V |
| Repetitive Peak Off-State Current | 3mA |
| Maximum Operating Temperature | +125 °C |
