Unlock smarter, more efficient circuit design with the Nexperia PIMC31,115, a rugged pre‑biased bipolar transistor pair engineered for industrial and automotive applications. This compact SOT457 (TSOP‑6) module integrates one NPN and one PNP transistor, each pre‑configured with bias resistors (R1 ≈ 1 kΩ, R2 ≈ 10 kΩ), optimizing board space and assembly efficiency.
Notable Advantages to Users
- Simplified Design & BOM Reduction: Pre‑biased resistors eliminate external components, streamline board layout, and cut assembly time.
- Automotive-Ready Quality: AEC-Q100 qualified for reliability under harsh environmental and thermal stress conditions.
- Robust Performance: Supports moderate power switching and signal buffering with low VCEsat and solid current capacity.
- Space-Saving SMT Form Factor: Compact TSOP-6 packaging supports high-density designs while maintaining ease of installation.
Product Usage Information
Ideal for load switching, input line drive, signal inversion, and digital protection circuits in automotive electronics, industrial control, and consumer devices.
Technical Specifications
- Collector Current (Ic max): 500 mA
- Collector‑Emitter Breakdown Voltage (VCEO): 50
- Bias Resistors: R1 = ~1 kΩ; R2 = ~10 kΩ
- DC Current Gain (hFE min): 70 @ 50 mA, 5 V
- Saturation Voltage (VCEsat): ≤ 300 mV @ Ic = 50 mA, Ib = 2.5 mA
- Power Dissipation (Pd): Up to ~420 mW (per device), ~290 mW per transistor, depending on mounting
- Temperature Range (Tj/Tamb): –55 °C to +150 °C
- Package Dimensions: 3.1 mm × 1.7 mm × 1 mm (L×W×H)
