Lapp ÖLFLEX CLASSIC 110 Control Cable, 3 Cores, 2.5 mm², YY, Unscreened, 50m, Grey PVC Sheath, 13 AWG

1119403 Lapp ÖLFLEX CLASSIC 110 Control Cable, 3 Cores, 2.5 mm², YY, Unscreened, 50m, Grey PVC Sheath, 13 AWG
1119403
1119403
HT27978
HT27978
Control Cable
brand logo

HT Part No. HT27978

Mfr. Part No. 1119403

Manufacturer: Lapp

Technical Documents: LAPP Cable to Gland Cross Reference-95746884(datasheets) Datasheet-b24debee(datasheets) Cable Selection Guide-a69c0773(datasheets) Catalogue - LAPP Main Catalogue-1f6fbbc2(datasheets) Brochure - Machine Tools-2619535d(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0
Units Per Unit Price
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series ÖLFLEX CLASSIC 110
Number of Cores 3
Cross Sectional Area 2.5 mm²
American Wire Gauge 13 AWG
Conductor Material Copper
Sheath Material PVC
Control Cable Type YY
Sheath Colour Grey
Screened/Unscreened Unscreened
Length 50m
Minimum Bend Radius Fixed - 4 x D Occasional flexing - 10 x D
Outer Diameter 8.1mm
Voltage Rating 300/500 V
Current Rating 26 A
CPR Certification Eca
Maximum Operating Temperature +80°C
Insulation Material PVC
Core Strands 50/0.25 mm
Earth Cable Yes
Conductor Resistance 7.98 Ω/km
Minimum Operating Temperature -40°C
Filler Material Non-Wicking Filler
Oil Resistant Yes

More Information

LAPP Control Cable, 300/500V Voltage Rating, 8.1mm OD - ÖLFLEX Series - 1119403 Securely send power and data across your industrial system with this control cable from LAPP. With its bare copper conductors, it forms effective electrical connections to ensure an efficient power supply. The hard-wearing PVC sheath means you can trust your connections are safe around oils, chemicals and flames. Thanks to an outer diameter of 8.1mm, the cable fits easily in busy systems, making it a versatile choice. Features & Benefits • Numbered conductor cores for easy identification during installation and maintenance
• High test voltage rating of 4kV for protection against electrical surges
• Non-wicking filler for effective corrosion resistance
• Broad operating temperature range between -40°C and +80°C to suit demanding industrial conditions Applications • Control panels
• Data processing
• Manufacturing industry Is this cable screened against EMI? No, this is an unshielded cable, which makes it a flexible option.
