HT Part No. HT22784
Mfr. Part No. BD677
Manufacturer: STMicroelectronics
Technical Documents: Datasheet-e08a505f(datasheets) ESD Control Selection Guide V1-38e92ccd(datasheets)
| Product Attributes | |
|---|---|
| Transistor Type | NPN |
| Maximum Continuous Collector Current | 4 A |
| Maximum Collector Emitter Voltage | 60 V |
| Maximum Emitter Base Voltage | 5 V |
| Package Type | SOT-32 |
| Mounting Type | Through Hole |
| Pin Count | 3 |
| Transistor Configuration | Single |
| Number of Elements per Chip | 1 |
| Minimum DC Current Gain | 750 |
| Maximum Collector Base Voltage | 60 V |
| Maximum Collector Emitter Saturation Voltage | 2.5 V |
| Maximum Collector Cut-off Current | 0.2mA |
| Dimensions | 7.8 x 2.7 x 10.8mm |
| Minimum Operating Temperature | -65 °C |
| Width | 2.7mm |
| Length | 7.8mm |
| Maximum Operating Temperature | +150 °C |
| Height | 10.8mm |
