Weidmuller PRO MAX Switched Mode DIN Rail Power Supply, 85 → 277 V ac / 80 → 370V dc ac, dc Input, 24V dc

1478110000 Weidmuller PRO MAX Switched Mode DIN Rail Power Supply, 85 → 277 V ac / 80 → 370V dc ac, dc Input, 24V dc
1478110000
1478110000
HT19193
HT19193
DIN Rail Power Supplies
brand logo

HT Part No. HT19193

Mfr. Part No. 1478110000

Manufacturer: Weidmüller

Technical Documents: PRO MAX-4a157b04(datasheets) 9236548_Catalogue-2168872a(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 114.47
Units Per Unit Price
1 + £ 114.47
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Type Switched Mode
Output Voltage 24V dc
Output Current 5A
AC or DC Input Voltage ac, dc
AC or DC Output Voltage dc
Input Voltage 85 → 277 V ac / 80 → 370V dc
Power Rating 120W
Electrical Phase 1
Number of Outputs 1
Height 130mm
Width 40mm
Depth 125mm
Series PRO MAX
Maximum Temperature +70°C
Standards Met 61000-4-4, 61000-4-5, 61000-4-6, CE Certified, cULus Listed, cULus Recognized, EAC, EN 50178/VDE 0160, EN 55022, EN 60204, EN 60950, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8, IEC 1709, IEC 60068-2-27, IEC 60068-2-6, IEC 61558-2-16, TUV, VDE 0100-410/DIN57100-410, VDE 0106-101
Efficiency 89%
Ripple And Noise <50mV
Special Features Durable, High Performance
Mounting Type DIN Rail Mount
MTBF >500000h
Minimum Temperature -25°C

More Information

Weidmuller DIN Rail Power Supply, 80 to 370V DC Input Voltage Range, 89% Efficiency - PRO MAX Series - 1478110000 In the market for an ultra-efficient PSU that can power through tasks in harsh environments? Opt for this DIN rail power supply from Weidmuller. It steps down input voltages of 85 to 277V AC or 80 to 370V DC to give you a safely regulated output of 24V DC, making it a breeze to charge battery-powered components. This unit's 89% efficiency rating means it wastes little energy as heat, so you can count on it to keep its cool. As it comes with comprehensive overload and short circuit protections, you can trust this all-rounder to shield you and your equipment from electrical hazards. Features & Benefits • Metal housing is resistant to corrosion
• Wide operating temperature range between -25°C and +70°C for use in demanding environments
• Ripple and noise of less than 50mV means minimal risk of equipment damage from voltage spikes
• LED indicator for ease of status monitoring Applications • Industrial automation
• Automotive manufacturing
• Wind power
• Mechanical engineering How long will this unit last? This unit's MTBF of over 500,000 hours means you can rest assured it's a long-lasting option.
