Murata Ferrite Bead (Chip Ferrite Bead), 1.6 x 0.8 x 0.8mm (0603 (1608M)), 600Ω impedance at 100 MHz, 700Ω impedance at

blm18eg601sn1d Murata Ferrite Bead (Chip Ferrite Bead), 1.6 x 0.8 x 0.8mm (0603 (1608M)), 600Ω impedance at 100 MHz, 700Ω impedance at
BLM18EG601SN1D
brand logo

HT Part No. HT24057

Mfr. Part No. BLM18EG601SN1D

Manufacturer: Murata

Technical Documents: Datasheet-3349cadd(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0
Units Per Unit Price
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package Type 0603 (1608M)
Impedance at 100 MHz 600Ω
Impedance at 1 GHz 700Ω
Current Rating 500mA
Type Chip Ferrite Bead
Dimensions 1.6 x 0.8 x 0.8mm
Length 1.6mm
Depth 0.8mm
Maximum DC Resistance 350mΩ
Height 0.8mm
Series BLM18EG
Material Ferrite
Application EMI Suppression Filter, GHz Band General Use (Low DC Resistance Type)

More Information

SMD 0603 Ferrite Filters- BLM18EG/GG/HB/HD/HE/HG/HK Series BLM series ferrite beads from Murata do not require a ground connection and are ideal for use in circuits with unstable ground lines. Excellent solder heat resistance is provided by the nickel barrier construction of the external electrodes. These ferrite beads are designed to function nearly as resistors at noise frequencies, leaving signal wave forms undistorted and reducing the possibility of resonance.

This series of ferrite beads are designed for general use applications.
