The Eaton 1025HC30‑RTR is a precision-engineered, high-current surface-mount (SMD) ceramic tube fuse from the 1025HC series, tailored for modern global B2B and technical applications. Featuring robust construction and fast-acting protection, this compact fuse delivers reliable overcurrent defense without compromising board space or performance.
Standout Features and Benefits of this Surface Mount Ceramic Tube Fuse
- Fuse Type: Fast blow, ceramic tube, optimized for swift interruption of fault currents.
- Current & Voltage Ratings: 30 A rated for 250 V AC and 72 V DC operations.
- Breaking Capacity: Capable of handling up to 100 A at 250 V AC and 500 A at 72 V DC, ensuring dependable performance in overload scenarios.
- Electrical Resistance: Ultra-low typical cold resistance of approximately 1.7 mΩ, preserving signal integrity and efficiency.
- Dimensions & Mounting: Compact footprint of around 10 mm × 3.15 mm (length × width), with a 2-SMD square-end block configuration, ideal for tight PCB layouts.
- Operating Temperature: Rated from –55 °C to +125 °C, engineered for demanding thermal environments.
Product Application Potential
This fuse offers a compelling blend of fast-response overcurrent protection and compact design, a vital choice for power supplies, VRMs, telecommunications, LED drivers, and industrial control modules. Its high breaking capacity and minimal resistance make it ideal for protecting sensitive electronics without adding bulk or parasitic losses.
