The Nexperia HEF4001BT,653 is an exceptionally robust quad 2‑input NOR gate, engineered for mixed-voltage digital logic environments. Featuring a broad operational voltage window of 3 V to 15 V, this device offers low-power CMOS performance, wide logic level tolerance, and integrated input clamp diodes for superior interface protection.
Product Core Features and Benefits Include
- Low quiescent current (~1 µA) ensures minimal power consumption in dormant modes.
- Output Current Capability: ±3.4 mA allows moderate load driving.
- Response Time: A propagation delay of ~40 ns (at 15 V, CL = 50 pF) ensures fast digital performance.
- Input Clamp Diodes protect against over-voltage conditions, enhancing system resilience.
- ESD Immunity: Robust protection exceeding HBM 2000 V and CDM 1000 V, aiding reliability under static discharge stress.
- Operating Temperature Range: –40°C to +125°C caters to industrial and demanding environments.
Usage Information
This NOR gate logic IC is perfect for industrial automation, telecommunications interfaces, legacy voltage domain bridging, and other environments where rugged performance, broad voltage tolerance, and compact mounting are essential.
