This part excels where board designers need compact, low-power, and robust logic-level conversion, especially when interfacing higher-voltage signals to modern low-voltage logic. Its over-voltage-tolerant input structure removes the need for external clamping diodes, simplifying designs and reducing component count. Up to 15 V, enabling safe logic-level conversion for interfacing higher-voltage signals to lower-voltage logic without damage.
Advanced Features and Benefits of this Inverter IC
- Hex Inverter (6‑Channel): Fully buffered outputs using CMOS low‑power technology, with minimal quiescent current, ideal for power-sensitive embedded systems.
- High Noise Immunity & Robust Design: Built for industrial reliability with latch-up performance >100 mA (JESD 78 Class II Level B) and JEDEC compliance (JESD7A & JESD8C) for high-speed CMOS logic.
- ESD Protection: Protects against electrostatic discharge with HBM >2000 V and CDM >1000 V, enhancing resilience in harsh environments.
- Wide Temperature Range: Reliable operation from −40 °C to +125 °C, suitable for industrial, automotive, and outdoor applications.
- Output Drive Capability: Delivers up to ±7.8 mA, ensuring clean signal integrity for moderate loads.
Product Use Cases
Ideal for industrial control systems, mixed-voltage communication modules, legacy interface logic, battery-backed systems, and any application requiring high-to-low logic translation.
