NXP 74HC00PW,118 Quad 2 Input NAND Gate IC TSSOP14

The Nexperia 74HC00PW,118 is a professional-grade quad 2-input NAND gate IC designed for a broad voltage range CMOS logic applications (VCC: 2.0 V to 6.0 V), enabling seamless integration across diverse digital systems. Packaged in 14‑TSSOP (~4.40 mm width) format for space-saving PCB layouts and ease of automation.

Product Unique Features and Benefits

• Clamp Diode Inputs: Safeguard against over-voltage and support interfacing to voltage levels beyond VCC, enhancing design robustness.
• Low-Power CMOS Technology: Offers high noise immunity and low power consumption, making it suitable for energy-efficient industrial and embedded systems.
• Temperature Range –40 °C to +125 °C: Guarantees reliable performance in thermal extremes, from chilled industrial chillers to heated automotive harnesses.

Versatility in Applications

Ideal for general-purpose digital logic, including industrial control circuits, embedded system glue logic, automotive infotainment modules, and telecom equipment, where robust voltage tolerance, compact footprint, and high-speed operation are essential.
