Isocom, 6N139 DC Input Optocoupler, Through Hole, 8-Pin DIP

6n139 Isocom, 6N139 DC Input Optocoupler, Through Hole, 8-Pin DIP
6N139
brand logo

HT Part No. HT21410

Mfr. Part No. 6N139

Manufacturer: Isocom

Technical Documents: Datasheet-d230c2d6(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0
Units Per Unit Price
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type Through Hole
Maximum Forward Voltage 1.7V
Number of Channels 1
Number of Pins 8
Package Type DIP
Input Current Type DC
Maximum Input Current 1 A
Isolation Voltage 5000 Vrms
Logic Output Yes
Minimum Current Transfer Ratio 500%
Series 6N139

More Information

The 6N139 is an optically coupled isolator. It consists of an infrared emitting diode and an integrated high gain photon detector to provide 3000Vdc electrical insulation, 500V/μS common mode transient immunity and extremely high current transfer ratio between input and output. Separate pins for the photo diode and output stage result in TTL compatible saturation voltages and high speed operation. Where desired the VCC and VO terminals may be tied together to achieve conventional photodarlington operation. A base access terminal allows a gain bandwidth adjustment to be made. High CTR - 800% Typical
3000V Isolation
High Output Current - 60mA
Low Input Current Requirement - 0.5mA
