SICK Background Suppression Photoelectric Sensor, Block Sensor, 30 mm → 300 mm Detection Range

wtb8-p2231 SICK Background Suppression Photoelectric Sensor, Block Sensor, 30 mm → 300 mm Detection Range
WTB8-P2231
WTB8-P2231
HT28499
HT28499
Photoelectric Sensors
Photoelectric Sensors
wtb8-p2231 SICK Background Suppression Photoelectric Sensor, Block Sensor, 30 mm → 300 mm Detection RangeSICK
brand logo

HT Part No. HT28499

Mfr. Part No. WTB8-P2231

Manufacturer: SICK

Technical Documents: Datasheet_WTB8-P2231-237de8fc(datasheets) Product_Segment-8402bd36(datasheets) Operating_Instructions-8ffad46d(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0
Units Per Unit Price
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Sensor Style Block
Detection Type Background Suppression
Detection Range 30 mm → 300 mm
Output Type PNP
Electrical Connection M8 4 Pin Connector
Maximum DC Voltage 30V
Terminal Type M8 Connector
Light Source LED
IP Rating IP67
Maximum Current 30 mA
Response Time <500 μs
Maximum Operating Temperature +55°C
Minimum Operating Temperature -25°C
Series W8
Mounting Type Panel Mount
Housing Material ABS
Standards Met CE Certified

More Information

W8 Series Photoelectric Sensors Sick W8 series high-quality, miniature photoelectric sensors are specially designed for close-range applications. Autocollimation, background suppression, and high switching frequencies of 2 kHz make these sensors ideal for a broad range of applications. The housing is designed with M3 threaded mounting holes that provide easy and secure mounting.
