Phoenix Contact, 5.08mm Pitch, MSTB 2.5/ 4-STF-5.08, 4 Way, , Pluggable Terminal Block, Plug, Plug-In, Screw

1778001 Phoenix Contact, 5.08mm Pitch, MSTB 2.5/ 4-STF-5.08, 4 Way, , Pluggable Terminal Block, Plug, Plug-In, Screw
1778001
1778001
HT25707
brand logo

HT Part No. HT25707

Mfr. Part No. 1778001

Manufacturer: Phoenix Contact

Technical Documents: Datasheet - 1778001-c6d8e307(datasheets) Line Drawing - MSTB 2.5/-STF-5.08-67f65f09(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0
Units Per Unit Price
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Pluggable Terminal Block Type Plug
Number of Contacts 4
Pitch 5.08mm
Series MSTB 2.5/ 4-STF-5.08
Number of Rows 1
Body Orientation Straight
Mounting Type Plug-In
Termination Method Screw
Current Rating 12A
Voltage Rating 320 V
Colour Green
Material Polyamide
3D Model https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=1703834&DisplayLogo=False

More Information

Phoenix Contact CLASSIC COMBICON MSTB 5.08mm PCB Terminal Blocks A range of Classic COMBICON MSTB 5.08 mm pitch plug-in cable mount terminal block connectors from Phoenix Contact. The user-friendly PCB terminals feature a 0.2 mm² to 2.5 mm² screw connection that forms a standard plug-in system for 320 V (III/2). CLASSIC COMBICON MSTB - Features and Benefits: • Secure screw connection
• Well-known connection principle allows you to use worldwide
• Maximum contact force gives low temperature rise
• Long service life
