The Nexperia 74HC4051PW,118 is a high-performance 8‑channel analog/digital multiplexer (SP8T) in a compact TSSOP‑16 surface-mount package. Designed for versatility, it supports both single- and dual-supply operation (2 V to 10 V single-supply or ±1.5 V to ±5 V), facilitating wide-range signal switching across diverse analog and digital systems.
Why Buy this Product?
This multiplexer delivers high-speed performance (on/off times < 60 ns, 180 MHz bandwidth), low power consumption, and reliable logic-level translation between ±5 V analog signals and 5 V logic domains. Built-in clamp diodes and “break-before-make” switching reduce signal interference, while robust ESD protection (HBM >2000 V, CDM >1000 V) enhances resilience in industrial settings.
Product Crucial Features and Benefits
- A wide supply range (2–10 V / ±1.5–5 V) provides design flexibility across various applications.
- Fast Switching: Ton ≈ 59 ns, Toff ≈ 49 ns, perfect for responsive analog routing.
- High-bandwidth (180 MHz) ensures signal fidelity even at high frequencies.
- Compact TSSOP‑16 Package: Slim form (≈4.4 mm width), ideal for space-critical PCBs.
- Low Leakage & Channel Matching: ≤ 400 nA leakage, with a tight On-resistance variation of ~6 Ω, ensuring precision.
- JEDEC-Compliant & ESD-Robust: Compliant with JEDEC standards, supports harsh environments with –40 °C to +125 °C rating.
Use Cases
Ideal for global B2B and technical deployments such as:
- Analog/digital signal routing
- Sensor array multiplexing (e.g., data acquisition, instrumentation)
- Mixed-voltage logic interfacing
- Industrial, test equipment, and automotive systems
