NXP MPX5700AP 15–700 kPa Absolute Pressure Sensor with Analog Output (Unibody SIP‑6)

The NXP MPX5700AP is a rugged, silicon-based absolute pressure sensor packaged in a six-pin SIP module, designed to deliver accurate analog voltage outputs across a broad range of 15 kPa to 700 kPa (approximately 2.18 PSI to 101.53 PSI). It features temperature compensation, low supply voltage requirements, and a durable unibody epoxy construction—making it a dependable, board-mounted solution for demanding environments.

What Benefits Do You Get?

With the MPX5700AP, you gain a pressure sensor that effortlessly balances precision with practicality. Thanks to its ±2.5% full-scale accuracy and built-in temperature compensation, you can trust reliable readings straight out of the box—no complex calibration needed. Its broad operating temperature range (–40 °C to +125 °C) ensures stable performance in extreme conditions, while its analog voltage output simplifies integration into existing systems.

Product Functional Highlights:

• Measures absolute pressure from 15 kPa to 700 kPa (approx. 2.18–101.53 PSI)
• Analog voltage output ranging from approximately 0.2 V to 4.7 V
• Operates on a 5 V supply (range: 4.75–5.25 V)
• Accuracy of ±2.5% full-scale across 0 °C to 85 °C
• Maintains functionality throughout an extended temperature range (–40 °C to +125 °C)
• Temperature-compensated design delivers stable output in variable environments
• Durable epoxy unibody construction ensures long-term reliability
• Through hole SIP 6 package, ideal for easy board mounting.
