The NXP MPX5050GP is a high-precision, analog gauge pressure sensor with a 0–50 kPa (0–7.25 psi) range. Built with advanced piezoresistive transducer technology, its integrated on‑chip signal conditioning, temperature compensation, and micromachined silicon design ensure dependable performance for global automotive and industrial applications.
Technical Specifications
- Operating Pressure: 0 to 50 kPa (0–7.25 psi)
- Output Voltage Range: Typically 0.2 V (offset) to 4.7 V (full‑scale) at +5 V supply
- Accuracy: ±2.5% FSS (Full‑Scale Span) across 0 °C to 85 °C
- Supply Voltage: 4.75 V to 5.25 V (nominal 5 V)
- Supply Current: Approximately 7 mA typical
- Package & Port: Compact Unibody‑6 (SO‑8) surface‑mount, with a 3.17 mm gauge pressure port
- Operating Temperature: –40 °C to +125 °C
- Sensitivity: ~90 mV/kPa
Unmatched Benefits to Customers
- High precision and stability with ±2.5% accuracy and temperature compensation from –40°C to +125 °C.
- Analog output range (0.2–4.7 V) directly interfaces with ADCs in microcontrollers, ensuring smooth integration.
- Compact, robust design and durable epoxy unibody construction promise reliable performance in harsh environments.
- A fully processed silicon transducer with on-chip amplification and compensation reduces the need for external components.
Use Cases
Excellent for automotive systems (e.g., BPMS, tire and vacuum monitoring), industrial control systems, and embedded process instrumentation. Its compact size, analog output, and reliability make it versatile for global OEMs, system integrators, and R&D engineers.
