HT Part No. HT230236
Mfr. Part No. AEP18024
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Keyword | relay power, guc rolesi, spst-no role, tek kontak role |
| Series | AEP |
| Coil Voltage | 24VDC |
| Operating Temperature | -40°C~+80°C |
| Contact Form | SPST-NO (1 Form A) |
| Coil Type | Non Latching |
| Contact Current (Max) | 120A |
| Contact Voltage | 400VDC |
| Relay Type | Relay Power |
| Contact Current (Nom) | 80A |
| Coil Current | 176mA |
| Coil Resistance | N/A |
| Coil Power | 4.20W |
| Packaging | BOX |
| Manufacturer | PANASONIC COMP. |
| Mounting Type | Chassis Mount |
| Length | 75.50mm |
| Width | 40.00mm |
| Height | 79.00mm |
| Rohs | ROHS |
| Number of Pins | None |
