HT Part No. HT230261
Mfr. Part No. SF4D-DC12V
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Manufacturer | PANASONIC COMP. |
| Coil Type | Non Latching |
| Coil Current | 41.70mA |
| Packaging | TRAY |
| Relay Type | Relay Safety |
| Series | SF |
| Operating Temperature | -40°C~+70°C |
| Length | 53.30mm |
| Number of Pins | 18 Pin |
| Mounting Type | THT |
| Contact Current (Nom) | 6A |
| Coil Resistance | 288 Ohms |
| Coil Power | 500mW |
| Height | 16.00mm |
| Contact Form | 8PST-NO/NC (4 Form A/4 Form B) |
| Contact Current (Max) | N/A |
| Coil Voltage | 12VDC |
| Contact Voltage | 250VAC/30VDC |
| Width | 33.00mm |
| Rohs | ROHS |
