HT Part No. HT230273
Mfr. Part No. TX2SA-12V
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Series | TX |
| Contact Form | DPDT (2 Form C) |
| Height | 8.20mm |
| Coil Voltage | 12VDC |
| Coil Current | 11.70mA |
| Coil Power | 140mW |
| Operating Temperature | -40°C~+85°C |
| Relay Type | Relay Telecom |
| Mounting Type | SMT |
| Length | 15.00mm |
| Manufacturer | PANASONIC COMP. |
| Coil Type | Non Latching |
| Contact Voltage | 220VDC - Max |
| Coil Resistance | 1.028K Ohms |
| Width | 7.40mm |
| Packaging | TUBE |
| Number of Pins | 8 Pin |
| Contact Current (Nom) | 2A |
| Contact Current (Max) | N/A |
| Rohs | ROHS |
