HT Part No. HT230274
Mfr. Part No. HL1-P-DC24V-S-H38
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Contact Current (Nom) | 10A |
| Contact Current (Max) | 15A |
| Coil Voltage | 24VDC |
| Manufacturer | PANASONIC COMP. |
| Contact Form | SPDT (1 Form C) |
| Keyword | relay power, guc rolesi, 1FormC role, cift kontak role |
| Number of Pins | 5 Pin |
| Length | 27.20mm |
| Relay Type | Relay Power |
| Coil Current | 37mA |
| Operating Temperature | -50°C~+70°C |
| Series | HL |
| Width | 20.80mm |
| Rohs | ROHS |
| Packaging | BULK |
| Mounting Type | THT |
| Coil Type | Non Latching |
| Contact Voltage | 125VAC/30VDC |
| Coil Resistance | 650 Ohms |
| Coil Power | 900mW |
| Height | 35.40mm |
