S4EB-12V - RELAY 4A 12V 4PNC (4 Form A)
HT Part No. HT230293
Mfr. Part No. S4EB-12V
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Length | 28.00mm |
| Packaging | TRAY |
| Coil Type | Non Latching |
| Contact Current (Max) | N/A |
| Coil Voltage | 12VDC |
| Operating Temperature | -55°C~+65°C |
| Relay Type | Relay Power Polarized |
| Coil Current | 16.70mA |
| Coil Power | 200mW |
| Rohs | ROHS |
| Series | S |
| Contact Form | 4PST-NO (4 Form A) |
| Contact Current (Nom) | 4A |
| Width | 12.00mm |
| Number of Pins | 12 Pin |
| Manufacturer | PANASONIC COMP. |
| Mounting Type | THT |
| Contact Voltage | 250VAC/30VDC |
| Coil Resistance | 720 Ohms |
| Height | 10.00mm |
S4EB-12V - RELAY 4A 12V 4PNC (4 Form A)
