HT Part No. HT230412
Mfr. Part No. JVN1AF-12V-F
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Relay Type | Relay Power |
| Coil Voltage | 12VDC |
| Width | 16.00mm |
| Contact Current (Nom) | 10A |
| Contact Voltage | 277VAC/30VDC - Max |
| Contact Form | SPST-NO (1 Form A) |
| Coil Type | Non Latching |
| Coil Resistance | 720 Ohms |
| Number of Pins | 4 Pin |
| Mounting Type | THT |
| Length | 22.00mm |
| Height | 10.50mm |
| Rohs | ROHS |
| Packaging | BULK |
| Keyword | relay power, guc rolesi, spst-no role, tek kontak role |
| Series | JVN |
| Contact Current (Max) | 16A |
| Coil Current | 16.70mA |
| Coil Power | 200mW |
| Operating Temperature | -40°C~+70°C |
| Manufacturer | PANASONIC COMP. |
