HT Part No. HT230414
Mfr. Part No. ALZN1B05W
Manufacturer: PANASONIC COMP.
Technical Documents: Datasheet(datasheets)
| Product Attributes | |
|---|---|
| Operating Temperature | -40°C~+85°C |
| Width | 12.50mm |
| Mounting Type | THT |
| Length | 28.80mm |
| Height | 15.70mm |
| Rohs | ROHS |
| Coil Type | Non Latching |
| Contact Current (Max) | N/A |
| Coil Voltage | 5VDC |
| Contact Voltage | 250VAC |
| Number of Pins | 8 Pin |
| Relay Type | Relay Power |
| Series | ALZN |
| Contact Form | SPDT (1 Form C) |
| Contact Current (Nom) | 16A |
| Coil Current | 80mA |
| Coil Power | 400mW |
| Manufacturer | PANASONIC COMP. |
| Coil Resistance | 63 Ohms |
| Packaging | TRAY |
| Keyword | relay power, guc rolesi, 1FormC role, cift kontak role |
